Unrated
(15 minutes)
Gad to use pucker to remove, tapped back in with small hammer
7/14/2023 TOULON, IL stevn
(18 minutes)
PROJECT: Removed/Repaired/Reinstalled both front axle gear case units on Kubota model BX2230D. R&R both front axle oil seals, R&R both front axle inner & outer bearings, R&R both front axle gear case upper dual-piece oil seals, R&R silicone sealant on both front axle gear case covers (Kubota Silicone Sealant Gray #70000-73764-620), reassembled both front axle gear case units, torqued front axle gear case covers mounting bolts, reinstalled both front gear case units to the front differential case, allowed sealant to cure overnight. The following morning serviced front differential system with 5 quarts 80/90 gear oil. Many various tools required to complete process; hand tools, torque wrench. gear puller, hydraulic press, etc. I found that a Coupling for 2 inch diameter scedule 40 PVC pipe worked nicely installing the front axle gear case upper dual-piece oil seals. Nothing easy about any part of this project.The time stated is from the start to the finish of this project.
6/11/2023 MARYVILLE, MO DANIEL
(1 hour)
Really easy if you have access to a press but its not required. Just take you time with a vise and a rubber hammer and you'll be fine.
4/9/2023 MEHERRIN, VA CRAIG
1/13/2023 MOORE, OK JUSTIN
use large nut socket to reset bearibg
10/8/2022 W JEFFERSON, NC j.
Unrated
(5 minutes)
Use either old bearing or spindle shaft to set new bearings. Tight fit as expected and easy to misalign if you are not careful.
8/16/2022 WEEDVILLE, PA Arnold
Unrated
(5 minutes)
Be sure to pre pack the bearing. Use the old bearing to tap in the new one.
use atf on shaft.
BURTON, OH
Scott
