Unrated
(30 minutes)
Installed while replacing front axle seal. About 30 minutes for whole job.
6/22/2022 TERRELL, TX Kerry
Unrated
Part of front axle and differential rebuild. Replaced all seals and bearings. Not that hard. Be sure and have snap ring pliers, press, bearing separator and pullers available. Hardest part is removing the snap rings. I removed complete unit by removing 4 bolts at end of axle. and did the rebuild on the workbench.
Remove the inside snap ring on the bevel gear case first. Pry and pull apart the 2 halves of the case then remove the snap ring inside the lower case housing. Some bearings will require puller or press to remove. On assembly remember to put the smaller snap ring on the shaft before inserting shaft and stearing bearings into the housing. Total time 3 to 4 hours but I had done this before.
Installed while replacing front axle seal. About 30 minutes for whole job.
TERRELL, TX
Kerry
