McFarlane Incite Universal Tillage

The Incite® 5100 Series is the industry’s first Universal Tillage® tool, redefining what’s possible with a single-pass vertical tillage machine. Designed to handle a wide range of field conditions, soil types, and crop residues, the Incite allows growers to adapt from season to season and field to field—minimizing passes while maximizing productivity. Its innovative features, like the Universal Tillage® Selector for hydraulic on-the-go gang angle adjustment, give you control, speed, and precision like never before. With working widths ranging from 14' to 51', this tool offers unmatched flexibility, durability, and performance for conservation and minimum-tillage operations.

Get a Quote

Used Unit Available

Ask a Question

Series Models

IC5124

23' 5" Cut Width, 13' 8" Transport Width, Weighs Approx 18,500 lbs, on-the-go disk angle adjustment from 3°, 6°and 9°. Hydraulic Dura-Reel® Height Adjust , Requires 4 Hydraulic Remotes

IC5120

20' 5" Cut Width, 13' 8" Transport Width, Weighs Approx 17,320 lbs, on-the-go disk angle adjustment from 3°, 6°and 9°. Hydraulic Dura-Reel® Height Adjust, Requires 4 Hydraulic Remotes

Series Models

IC5124

23' 5" Cut Width, 13' 8" Transport Width, Weighs Approx 18,500 lbs, on-the-go disk angle adjustment from 3°, 6°and 9°. Hydraulic Dura-Reel® Height Adjust , Requires 4 Hydraulic Remotes

IC5120

20' 5" Cut Width, 13' 8" Transport Width, Weighs Approx 17,320 lbs, on-the-go disk angle adjustment from 3°, 6°and 9°. Hydraulic Dura-Reel® Height Adjust, Requires 4 Hydraulic Remotes

Considering Used?

More Used Equipment

Mcfarlane - IC5124

23' 5" cutting width, 13' 8" transport width, weighs approx. 18,500 pounds, The Incite is an evolution in vertical tillage, as it provides the flexibility to adjust to different soil types and conditions from field-to-field and from year-to-year. The versatility of this tillage tool allows conservation tillage and minimum-tillage growers to accomplish in a single pass what once would take multiple passes with different tillage equipment, on-the-go disk angle adjustment from 3°, 6°and 9°. INCIZOR® Blades - Unique blade featuring 22" diameter 6mm razor-sharp reversed crimped blades for greater strength. Capable of 6" depth, Hydraulic Dura-Reel® Height Adjust - Adjustable reel depth from disk depth to 8" above the bottom of the disk blade. Dura-Reel® Patent pending - 7-blade 18" diameter open center reel with no center shaft for better material flow and resists plugging in wet, sticky soil with 5-Bolt hubs for added strength and durability. Double Rolling Baskets - Provides the finishing touch with 8-high carbon flat bars that have adjustable down pressure to meet varying field conditions. Convenient settings for more aggressive clod sizing or less aggressive for soil separating. Its flexibility allows residue to flow and easily raises or lowers to conform to various soil and residue conditions. 8 bolt 320/70R15 Tires on walking tandems on main frame, and 6 bolt 280/70R16 tires on walking tandems on wings. Requires 4 hydraulic remotes View Details

Key Features

Universal Tillage® Selector – On-the-go disc gang angle adjustments at 3°, 6°, or 9°.
Hydraulic Dura-Reel® Height Adjust – Set reel height from blade depth up to 8" above.
INCIZOR® Blades – 22" diameter, 6mm crimped, razor-sharp blades capable of 6" tillage depth.
Dura-Reel® (Patent Pending) – 7-blade, 18" open-center reel prevents plugging and improves flow.
5-Bolt Reel Hubs – Provide added strength and long-term durability.
Rolling Basket – Adjustable down pressure with 8 high-carbon flat bars for residue management.
3-Bar Spike Tooth Harrow – Follows terrain and adapts to varying soil/residue conditions.
Swept Back Reel Design – Increases residue and rock clearance.
Articulating Ball Hitch – Reduces fatigue on drawbars; better connection for folding models.
Maintenance-Free Walking Tandem Axle – On both mainframe and wing sections.
Spring Cushion Level Lift – Absorbs shock in uneven terrain.
Single Point Depth Stop – Simple and quick depth adjustments.
GBGI Hubs – Low-maintenance sealed cast hub bearings for added durability.
Service-Free Trunnion Bearings – Sealed design with 1¾" round center shaft.
UHMW Axle Bearing – 6mm thick, long-wearing composite bearing.

IC5112

Cutting Width: 12' 5"
Approx. Weight: 10,100 lbs
Transport Height: N/A
Transport Width: 13' 9"
Approx. HP Required: 100–150 HP
Acres/hour @ 6–9 mph: 7–11

IC5114

Cutting Width: 13' 6"
Approx. Weight: 10,700 lbs
Transport Height: N/A
Transport Width: 14' 10"
Approx. HP Required: 120–180 HP
Acres/hour @ 6–9 mph: 8–12

IC5120

Cutting Width: 20' 5"
Approx. Weight: 17,320 lbs
Transport Height: 10' 6"
Transport Width: 13' 8"
Approx. HP Required: 163–245 HP
Acres/hour @ 6–9 mph: 15–20

IC5124

Cutting Width: 23' 5"
Approx. Weight: 18,500 lbs
Transport Height: 12' 0"
Transport Width: 13' 8"
Approx. HP Required: 188–282 HP
Acres/hour @ 6–9 mph: 15–22

IC5127

Cutting Width: 26' 6"
Approx. Weight: 20,920 lbs
Transport Height: 11' 5"
Transport Width: 15' 7"
Approx. HP Required: 212–318 HP
Acres/hour @ 6–9 mph: 16–24

IC5132

Cutting Width: 32' 1"
Approx. Weight: 25,220 lbs
Transport Height: 13' 6"
Transport Width: 15' 7"
Approx. HP Required: 256–384 HP
Acres/hour @ 6–9 mph: 19–29

IC5140

Cutting Width: 39' 7"
Approx. Weight: 30,730 lbs
Transport Height: 11' 7"
Transport Width: 18' 8"
Approx. HP Required: 320–408 HP
Acres/hour @ 6–9 mph: 24–36

IC5151

Cutting Width: 51' 3"
Approx. Weight: 40,500 lbs
Transport Height: 14' 8"
Transport Width: 19' 2"
Approx. HP Required: 408–602 HP
Acres/hour @ 6–9 mph: 31–46
